galvanized glazed tile making machine for building

  • galvanized glazed tile making machine for building
  • galvanized glazed tile making machine for building
  • galvanized glazed tile making machine for building
  • galvanized glazed tile making machine for building

galvanized glazed tile making machine for building

    Unit Price: 16000 USD
    Min. Order: 1 Set/Sets
    Packaging: BARE PACKING WITH WATERPROOF, ONE MACHINE NEEDS ONE 20FEET CONTAINER.
    Transportation: Ocean
    Place of Origin: China
    Supply Ability: 200 Set/Sets per Year
    HS Code: 84552210
    Port: TIANJIN

Basic Info

Model No.: YY-001

Product Description

Specification:

 Main Technicial Parameter:



1

Inner diameter of manual decoiler

500mm

2

Outer diameter of manual decoiler

1200mm

3

Weight capacity of manual decoiler

5T

4

Appearance Size

8500mm*1550mm*1300mm

5

Raw Material

colored steel or galvanized steel

6

Roller material

high grade 45# forged steel,polished,heated,quenched

7

Blade Material

CR12 with polished

8

Chrome Coating

coated with 0.05mm hard chrome

9

Control System

PLC control

11

Hydraulic Power

7.5 KW

12

Roller station

13 rollers

13

Material of chain

high grade 45# steel:polished,heated,quenched HRC 45-50

14

Speed of Product

0-12m/min

15

Thickness range

0.2-0.8mm

16

Type of cutting

hydraulic cutting

17

Coil Width

1250mm

18

Cover Width

1100mm

19

Material of rack

complete welded structure of A3 steel plate

20

Machine frame stand

welded with 300H-steel

21

Type of forming machine

single station with chain transmission

22

Thickness of side-wall

16mm

23

Shaft Diameter

75mm

24

Weight

about 4 T

25

Voltage

380V 50HZ 3Phases( or as your local requirement)

26

Electrical control

PLC frequency control system








Pictures:

galvanized glazed tile making machine for building



galvanized glazed tile making machine for buildinggalvanized glazed tile making machine for building

 galvanized glazed tile making machine for buildinggalvanized glazed tile making machine for building



Processing:



Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Step formed



→ Auto cutting→Products receivinggalvanized glazed tile making machine for building







Our Services

 galvanized glazed tile making machine for buildinggalvanized glazed tile making machine for buildinggalvanized glazed tile making machine for building





Packaging & Shipping

 galvanized glazed tile making machine for building



Company Information



Shijiazhuang Yingyee Import&Export Co., Ltd.

YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor from all the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment.

Our products were sold to more than 20 countries already. Also included US and Germany.

Main product :

 Roof roll forming machine

 C and Z purlin roll forming machine

 Downpipe roll forming machine

 Hydraulic decoiler

 Light keel roll forming machine6

 Bending machine

 Shearing machine

 slitting machine

 Roller shutter door roll forming machine



FAQ



Training and Installation
1 We offer installation service local in paid, reasonable charge.
2 QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.

Certification and after service
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.

Our advantage:
1. Short delivery period.
2. Effective communication
3. Interface customized.
